| P
|
螺距 |
| da
|
最大值 |
| ds
|
最大值 |
| 最小值 |
| dw
|
最小值 |
| dk
|
最大值 |
| k
|
公称 |
| 最大值 |
| 最小值 |
| k1
|
最小值 |
| k2
|
最大值 |
| r
|
最小值 |
| d0
|
≈ |
| db
|
公称 |
| 最大值 |
| 最小值 |
| dc
|
≈ |
| de
|
≈ |
|
| 2 |
2.5 |
2.5 |
3 |
3 |
3.5 |
| 18.83 |
24.4 |
26.4 |
28.4 |
32.84 |
35.84 |
| 16.43 |
20.52 |
22.52 |
24.52 |
27.84 |
30.84 |
| 15.57 |
19.48 |
21.48 |
23.48 |
26.16 |
29.16 |
| 27.9 |
34.5 |
38.5 |
41.5 |
42.8 |
46.5 |
| 30 |
37 |
41 |
44 |
50 |
55 |
| 10 |
13 |
14 |
15 |
17 |
19 |
| 10.75 |
13.9 |
14.9 |
15.9 |
17.9 |
20.05 |
| 9.25 |
12.1 |
13.1 |
14.1 |
16.1 |
17.95 |
| 12 |
14 |
15 |
16 |
17 |
18 |
| 17 |
19 |
21 |
23 |
24 |
25 |
| 1.2 |
1.2 |
1.2 |
1.6 |
2 |
2 |
| 10.9 |
13.6 |
15.1 |
16.4 |
18.6 |
20.6 |
| 11.1 |
13.9 |
15.4 |
16.7 |
19 |
21.1 |
| 11.3 |
14.1 |
15.6 |
16.9 |
19.3 |
21.4 |
| 11 |
13.8 |
15.3 |
16.6 |
18.7 |
20.8 |
| 12.8 |
16.1 |
17.8 |
19.3 |
21.9 |
24.4 |
| 13 |
17 |
18 |
20 |
22 |
24 |
|
